KYN28-20 Indoor Metal – Clad Withdrawable Switchgear
The 20kV indoor metal armored withdrawable switchgear is an ultra-high voltage equipment designed for high-end industrial and new energy scenarios worldwide. It complies with GB/T 3906-2020, IEC 62271-200, and ANSI C37.20.7 standards and is suitable for high-end scenarios such as overseas large-scale petrochemicals, cross-border power grid connections, and large-scale new energy bases. The equipment adopts an ultra-high voltage composite insulation armor structure, integrating intelligent monitoring, global standard compatibility, and ultra large load adaptation technology. It has the characteristics of excellent rated parameters, ultimate safety performance, and low life cycle cost, and can achieve efficient transmission, intelligent regulation, and fault prediction of ultra-high voltage electrical energy.
Features
1. Global multi standard compatibility, overseas high-end adaptation:
Simultaneously meeting the three major system standards of national standard, IEC, and ANSI, it can customize 50Hz/60Hz frequency, different wiring methods, and instrument configurations, adapting to most high-end industrial projects in Europe, America, the Middle East, and other regions around the world, without the need for additional modifications to land.
2. Ultra large load redundancy, top-notch parameter performance:
rated current can reach 2500A-4000A, short-circuit breaking capacity of 80kA-100kA, short-term withstand current of 80kA (3s), with sufficient parameter redundancy, suitable for ultra large petrochemical plants, cross-border power grid connections and other ultra large load scenarios.
3. Breakthrough in composite insulation and ultra-high voltage safety guarantee:
Adopting solid insulation+SF6 mixed insulation technology, the insulation level reaches 50kV level, greatly reducing the cabinet volume. At the same time, equipped with multi-dimensional online monitoring systems for partial discharge, insulation, and temperature, real-time warning of safety risks and prevention of ultra-high voltage failures.
4. Intelligent collaborative regulation and adaptation to new energy grid connection:
It can seamlessly integrate with wind power, photovoltaic, and energy storage systems, support wide voltage input and reactive power compensation, and has the ability to adapt to new energy generation fluctuations. It can achieve multi energy collaborative regulation and ensure grid stability.
5. Global operation and maintenance support, high-end service adaptation:
providing global parts warehousing and 24-hour multilingual technical support, equipped with an overseas on-site engineer team, can provide customized operation and maintenance solutions and full lifecycle technical services, adapted to the operation and maintenance needs of overseas high-end projects.
The product supports SF6 insulated circuit breaker or full vacuum circuit breaker configuration, with optional permanent magnet operating mechanism, and a mechanical life of up to 150000 times; The default protection level is IP54, which can be upgraded to IP65. Explosion proof scenarios can be customized with Ex d IIC T4 explosion-proof type; The intelligent module supports IEC 61850-9-2 and DNP3.0 high-speed communication protocols, achieving millisecond level data exchange; Provide global certifications such as UL, CE, ANSI, and national level type test reports to meet the requirements for high-end project access.
